please select HUIYUE transformer bushing auto through machine manufacturer.

HY-K06 two-door mobile automatic temperature oven Details
Thermostatic oven Main Specifications
Studio Size: height 1100mm, width 500mm, depth 600mm
Dimensions: height 2000mm, width 1500mm, 850mm deep
Studio material: A3 board
Studio stratified: 10 layers, each placed a baking tray.
Outer material: cold steel, re-paint the surface.
Working temperature: room temperature ~ 300 ℃ arbitrary regulation
Temperature accuracy: ± 1 ℃ temperature control mode: PID dual digital intelligent temperature control, key settings, the setting value and the actual temperature LED digital display. Power supply voltage: 380V (three-phase four-wire), 50HZ
Heating equipment: stainless steel heating pipe; life of up to 40,000 hours
Heating power: 12KW
Air mode: dual duct vertical air
Blowing device: the long axis of the motor as well as high-temperature oven oven dedicated multi-wing wind wheel
Timing devices: 1 minute to 99.9 hours thermostat timer, preset baking time, time to automatically cut off the heating and buzzer alarm
Factory accessories: matching stainless steel angle grid 2
Options: 1, can increase or decrease the number of compartment; 2, box pin can be replaced with mobile casters
Other specifications: the actual needs of a variety of customized according to user and function oven (oven / oven)

Features
1. The hot air circulation duct design clever, hot air circulation in the oven with high coverage, uniform drying and energy saving
2. Dual digital intelligent instrument temperature control, simple PID calculation, automatic control, temperature, operation, precise temperature control
3.1 seconds - 99.99 hours for any set time, automatically stop heating time is reached, and buzzer alarm
The oven durable, can work 24 hours a day thermostat
5. You can adjust the internal dimensions of the actual demand, housing color, the maximum temperature, heating speed, bearing the weight, number of layers shelving way, and does not necessarily additional cost

Scalable function
1. The over-temperature protection device to prevent the temperature control failure continues to heat up, baked goods security guarantee
2. Print temperature record
3. The exhaust air vents can be equipped with means

Studio Size-demand, and we provide nine conventional size for reference or choose
Model Voltage Power Operating temperature range ℃ Temperature sensitivity ℃ within the frame size
H * W * D (mm) L heat
Type 1 220V 2.5KW room temperature -300 ℃ ± 1 300 * 300 * 300 27L electric heating
Type 2 220V 3KW room temperature -300 ℃ ± 1 450 * 450 * 450 70L electric heating
3 type 380V 3.6KW room temperature -300 ℃ ± 1 550 * 550 * 450 136L electric heating
4 type 380V 4.5KW room temperature -300 ℃ ± 1 750 * 600 * 500 225L electric heating
5 type 380V 9KW room temperature -300 ℃ ± 1 1000 * 800 * 800 640L electric heating
6 type 380V 12KW room temperature -300 ℃ ± 1 1000 * 1000 * 1000 1000L electric heating
7 type 380V 15KW room temperature -300 ℃ ± 1 1200 * 1200 * 1000 1440L electric heating
8 type 380V 21KW room temperature -300 ℃ ± 1 1500 * 1200 * 1000 1800L electric heating
9 type 380V 27KW room temperature -300 ℃ ± 1 1500 * 1500 * 1200 2700L electric heating
